OQ3.81-Right-angle Close (With latch holder)

Product description
: OQ3.81-Right-angle Close (With latch holder)
: 3.81
: 2P~24P
: OQxx37510000G

Please refer to the pdf file. The website drawing is for reference only. For details, please contact sales.

电气性能-Electrical
安规类别/Safety category:cULus  VDE
额定电压/Voltage rating:300V  300V
额定电流/Current rating:10A  10.5A
适用线经/Wire range:
单芯线经（AWG）/Solid wire(AWG):
多芯线经（AWG）/Stranded wire(AWG):
最大锁紧扭力/Torque:
螺丝规格/Screw:
剥线长度/Wire strip length:
耐电压值（1分钟）/Withstanding Voltage:1.6KV  2.5KV
安全认证/Safety Approval:
操作温度/Operating temperature:-40℃ to +115℃
焊锡温度/Soldering temperature:250℃±10℃ /5Sec

产品料号编码原则-How to order

OQ
XX
Poles		X
Pitch		X
Body type		X
Color		X
PCB Mounting
X
3
X
X

X

Solid Block
02 2contacts
03 3contacts
... ...
24 24contacts

33.81/.15"
2 close
5 With flange

0 Black
5 Green
6 Blue
8 Grey

1 Right-angle
030 0 Standard

Any special item by customer request,
please contact sales department.
G RoHS compliant
(lead<4%)
In copper Alloy

H RoHS compliant
(lead<1000ppm)
In copper Alloy
